CP Plus 16 Port Giga PoE Switch with SFP Port (CP-DNW-GPU16G2F2-20)

The CP Plus CP-DNW-GPU16G2F2-20 is a 20-port Gigabit PoE switch designed for high-performance networking environments, such as IP surveillance systems and enterprise networks. This unmanaged switch offers robust features to ensure reliable and efficient data transmission.

🔧 Key Specifications

• Ports:

  • 16 × 10/100/1000 Mbps RJ45 PoE ports

  • 2 × Gigabit RJ45 uplink ports

  • 2 × Gigabit SFP uplink ports

• PoE Standards: IEEE 802.3af/at

• PoE Power Budget: 200W total; up to 30W per port

• Switching Capacity: 40 Gbps

• Packet Forwarding Rate: 29.76 Mpps

• MAC Address Table: 8K entries

• Transmission Distance:

  • Standard mode: up to 100 meters

  • Extend mode (ports 9–16): up to 250 meters at 10 Mbps

• Protection:

  • ESD: Air discharge ±8KV, Contact discharge ±6KV

  • Surge: Common mode ±4KV, Differential mode ±2KV

• Power Supply: Built-in, 110–240V AC, 50/60Hz

• Dimensions: 320mm × 207mm × 44mm

• Weight: 1.78 kg

For more detailed information, you can refer to the official CP Plus product page.
