D-Link CAT6 305M Outdoor UTP Copper Cable – Black

Upgrade your outdoor network infrastructure with the high-performance D-Link CAT6 305M Outdoor Cable. Designed for durability and exceptional signal integrity, this unshielded twisted pair (UTP) cable is perfect for outdoor installations that demand superior speed, reliability, and resilience.

Key Features:

• High-Speed Performance: Supports Gigabit Ethernet (1000Base-T) with a bandwidth of up to 250 MHz.

• Pure Copper Conductor: Solid bare electrolytic-grade copper (23AWG) ensures excellent conductivity and minimal signal loss.

• Durable Outdoor Design: UV-resistant and PE-sheathed for protection against harsh weather conditions.

• Standards Compliant: Exceeds TIA/EIA-568-C.2, ISO/IEC 11801, RoHS, UL 444, and IEC 61156-5 standards.

• Advanced Construction: Includes a UV-PE jacket, polyethylene insulation, and a central slit film cross filler for stability and performance.

• Reliable Electrical Parameters:

  • Conductor resistance: 9.38Ω/100m

  • Dielectric strength: 1.7 KV AC

  • Insulation resistance: 5000 MΩ/km

  • Impedance: 100 ± 15%

• Environment-Ready: Operating and storage temperature range from -20°C to 60°C.

• Flame Tested: Meets NEC Article 800 and IEC 60332-1-2 fire safety standards.

Specifications:

• Length: 305 meters (reel packaging)

• Color: Black

• Outer Diameter: Approx. 7.1 mm

• Markings: Sequential meter markings for easy installation tracking

Ideal for high-performance outdoor networking applications, surveillance systems, or long-distance LAN connections, the D-Link CAT6 cable combines durability with data integrity—making it the trusted choice for both residential and commercial installations.

Model: NCB-C6UBLKR-305-O
Brand: D-Link
