Honeywell 10 Channel 4K NVR | I-HNVR-1110

The Honeywell I-HNVR-1110 is a powerful and reliable 10-channel Network Video Recorder (NVR) designed for modern IP surveillance systems. With support for up to 8MP cameras, 4K display output, and advanced compression technology, it delivers efficient recording, optimized storage, and seamless remote monitoring.

🔑 Key Features

✔ 10 Channel IP Camera Support
✔ Supports up to 8MP Resolution Recording
✔ Advanced IH+265 / H.265 / H.264 Compression
✔ 4K HDMI Output + VGA Output
✔ 1 SATA HDD Support (Up to 10TB)
✔ ONVIF Compatible (Third-party camera support)
✔ Plug & Play Operation

🎯 Video & Performance

• Video Input: 10 Channels

• Maximum Resolution: Up to 8MP

• Incoming Bandwidth: 50 Mbps

• Outgoing Bandwidth: 40 Mbps (Honeywell)

• Multi-channel live view and playback

🖥 Video Output

• HDMI Output: Up to 4K (3840 × 2160)

• VGA Output: Up to 1080p

• Simultaneous HDMI & VGA display

• Screen Split Modes: 1 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10

💾 Storage

• HDD Interface: 1 SATA Port

• Maximum Capacity: Up to 10TB (Single HDD)

• Advanced compression reduces storage usage significantly

🔄 Recording & Playback

• Recording Resolutions:
  8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 720P / VGA

• Multi-channel synchronous playback

• Video encryption supported

🌐 Network & Connectivity

• Network Interface: 1 × RJ45 (10/100 Mbps)

• Supported Protocols:
  TCP/IP, HTTP, DHCP, DNS, RTSP, NTP, UPnP, IPv4/IPv6

• ONVIF Profile S/T compatible

• Remote access via mobile app, CMS, and web browser

🔌 External Interfaces

• USB Ports: 2 × USB 2.0

• Audio Output: 1 × RCA

• USB backup and mouse support

⚙️ Smart Features

• Motion Detection

• Event Alerts & Notifications

• Video Content Analysis (VCA)

• Centralized IP camera management

• Real-time monitoring

⚡ Power

• Power Supply: DC 12V

• Power Consumption: ≤10W (without HDD)

🛡 Build & Design

• Compact 1U Desktop Design

• Designed for 24×7 continuous operation

• Operating Temperature: -10°C to +55°C

• Humidity: 10%–90% RH

📐 Physical Specifications

• Dimensions: 255 × 231 × 44 mm

• Weight: ~0.8 kg (without HDD)

📦 Applications

✔ Home CCTV Systems
✔ Offices & Retail Stores
✔ Warehouses & Factories
✔ Clinics & Schools
✔ Small to medium surveillance projects

💡 Why Choose I-HNVR-1110?

• Supports high-resolution IP cameras

• Efficient storage with advanced compression

• Easy installation and user-friendly interface

• Reliable Honeywell performance

• Ideal for scalable CCTV setups
