Honeywell 20 Channel 2-SATA 4K NVR | I-HNVR-1220

The Honeywell I-HNVR-1220 is a powerful 20-channel Network Video Recorder (NVR) designed for medium to large-scale IP CCTV installations. With dual HDD support, high bandwidth, and 4K output, it ensures reliable recording, efficient storage, and smooth system performance.

🔑 Key Features

✔ 20 Channel IP Camera Support
✔ Supports up to 8MP Resolution Recording
✔ Dual SATA HDD Support (2 HDD)
✔ Advanced IH+265 / H.265 / H.264 Compression
✔ 4K HDMI Output + VGA Output
✔ ONVIF Compatible (Third-party camera support)
✔ Plug & Play Operation

🎯 Video & Performance

• Video Input: 20 Channels

• Maximum Resolution: Up to 8MP

• Incoming Bandwidth: Up to 120 Mbps

• Outgoing Bandwidth: Up to 100 Mbps

• Multi-channel live view and playback

🖥 Video Output

• HDMI Output: Up to 4K (3840 × 2160)

• VGA Output: Up to 1080p

• Simultaneous HDMI & VGA display

• Screen Split Modes:
  1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 12 / 13 / 16 / 20

💾 Storage

• HDD Interface: 2 × SATA Ports

• Maximum Capacity: Up to 10TB per HDD (Total 20TB)

• Advanced compression reduces storage usage significantly

🔄 Recording & Playback

• Recording Resolutions:
  8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 720P / VGA

• Multi-channel synchronous playback

• Smart search and efficient playback

• Video encryption supported

🌐 Network & Connectivity

• Network Interface: 1 × RJ45 (10/100/1000 Mbps)

• Supported Protocols:
  TCP/IP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, IPv4/IPv6

• ONVIF Profile S/T supported

• Remote access via mobile app, CMS & web browser

🔌 External Interfaces

• USB Ports: 2 × USB 2.0

• Audio Output: 1 × RCA

• Supports USB backup and mouse

⚙️ Smart Features

• Motion Detection

• Event Alerts & Notifications

• Video Content Analysis (VCA) support

• Smart playback & search

• Centralized camera management

⚡ Power

• Power Supply: DC 12V

• Power Consumption: ≤10W (without HDD)

🛡 Build & Design

• Compact 1U Rack/Desktop Design

• Designed for 24×7 continuous operation

• Operating Temperature: -10°C to +55°C

• Humidity: 10%–90% RH

📐 Physical Specifications

• Dimensions: Approx. 272 × 341 × 47 mm

• Weight: ~1.5–1.6 kg (without HDD)

📦 Applications

✔ Offices & Commercial Buildings
✔ Warehouses & Factories
✔ Retail Chains & Showrooms
✔ Schools & Hospitals
✔ Medium to Large CCTV Projects

💡 Why Choose I-HNVR-1220?

• Dual HDD support for higher storage capacity

• High bandwidth for smooth multi-camera performance

• Supports up to 20 cameras

• Efficient compression saves storage cost

• Reliable Honeywell surveillance solution
